| 브랜드 이름: | Sinuo |
| 모델 번호: | SN5511C-1000L |
| MOQ: | 1 |
| 가격: | Customized |
| 지불 조건: | 티/티 |
| 공급 능력: | 1 세트/월 |
| Cooling Method | Air-cooled |
| Temperature Range | -40℃ to +70℃ |
| Temperature Fluctuation | ≤ 0.5℃ (ambient pressure, no load) |
| Temperature Deviation | ≤ ±2.0℃ (ambient pressure, no load) |
| Heating Time | 20℃ to +100℃, ≤ 30 min (ambient pressure) |
| Cooling Time | 20℃ to -40℃, ≤ 30 min (ambient pressure) |
| Pressure Range | Ambient pressure to 5 kPa (commonly 11.6 kPa) |
| Pressure Deviation | ≤ ±2 kPa (≥ 40 kPa) / ≤ ±5% (2-40 kPa) |
| Pressure Fluctuation | ≤ ±2 kPa (1 bar ~ 40 kPa); ≤ ±5% (40 kPa ~ 2 kPa) |
| Depressurization Time | ≤ 30 minutes to 5 kPa |
| Sample Specifications | Selectable voltage: 12V, 24V, 36V, 48V Max battery size: 720*480*600 mm Weight: 280 kg Max voltage: 56V Max current: 300A |
| Inner Chamber Dimensions | 1000*1000*1000 mm (W*H*D) |
| Outer Dimensions | 3250*1400*2000 mm (excluding protrusions) |
| Outer Wall Material | 1.5 mm painted iron sheet |
| Inner Wall Material | SUS304 stainless steel (5 mm, pressure-bearing structure) |
| Insulation Material | Rigid polyurethane foam |
| Chamber Door | Single door with explosion-proof handle, viewing window, internal lighting |
| Lead-through & Terminal Posts | One Φ100 mm lead-through on left side; sealed terminal flange |
| Manual Inflation Valve | For manual pressure equalization during power failure |
| Shelves | Two stainless steel shelves |
| Chamber Heater | Stainless steel finned tube heater |
| Heater Control | SSR (solid state relay) pulse-width modulation |
| Vacuum Pump | VD401 ULVAC direct-drive, air-cooled, single-stage rotary vane vacuum pump |
| Vacuum Sensor | UNIK 5072 (GE, USA), Range: 0-200 kPa, Accuracy: ±0.2% FS.BSL |
